| VT04 IR Thermometer Specifications |
|---|
| Detector type | Uncooled pyroelectric ceramic | | Thermal sensitivity (NETD) | < or = 250mK | | Field of view | 28 x 28 degrees | | Image Palettes | Hot Metal, Ironbow, Rainbow, Rainbow High Contrast, Grayscale (white hot) and Grayscale (black hot) | | Temperature range | 14 to 482 degrees F (-10 to +250 degrees C) | | Image file format | .is2 format saved to SD card; user can create professional reports or export images using supplied software (BMP, DIB, GIF, SPE, FIF, SPEG, JPG, PNG, TIF and TIFF) | | Safety compliances | CFR47: 2009 Class A. Part 15 subpart B; CE: EN 61326:2006; IEC/EN 61010-1:2010 Pollution Degree 2, 2 m drop | | Computer interface | Micro USB connector | | Power | Rechargeable Li-ion battery, 3.6V, 2250 mAh, 8.1 Wh; 8 hour life | | Dimensions (H x W x D) | 8.3 x 3 x 2.2 inches/21 x 7.5 x 5.5 cm | | Weight | 10.5 oz./300 g |
| 117 Multitester Specifications |
|---|
| Maximum voltage between any terminal and earth ground | 600V | | DC millivolts range and resolution | 600.mV range with 0.1mV resolution | | DC volts range and resolution | 6.000V range with 0.001V resolution; 60.00V range with 0.01V resolution; 600.00V range with 0.1V resolution | | AC millivolts (true RMS) range and resolution | 600.0mV resolution with 0.1mV resolution | | AC volts (true RMS) range and resolution | 6.000V range with 0.001V resolution; 60.00V range with 0.01V resolution; 600.0V range with 0.1V resolution | | Continuity range and resolution | 600 ohms range with 1 ohm resolution | | Ohms range | up to 600.0 ohms | | Diode test | 2.000V | | Capacitance | 1000 nanofarads to 1000 microfarads | | LoZ capacitance | 1 nanofarads to 500 microfarads | | Certifications | UL, CSA, TUV, N10140 , VDE, IP42 | | Safety compliances | ANSI/ISA 82.02.01 (61010-1) 2004; CAN/CSA C22.2 No 61010-1-04; UL 6101B (2003); EMC EN61326-1; and IEC/EN 61010-1 2nd Edition for measurement Category III, 600 V, Pollution Degree 2 |
| 376 Clamp Meter Specifications |
|---|
| AC/DC current measurement (fixed jaw) | 1,000 amp | | AC/DC current measurement (iFlex current probe) | 2,500 amp AC | | AC/DC voltage | 1,000V | | Frequency (jaw and iFlex) | Up to 500Hz | | Resistance with continuity detection | 60 kilohms | | DC millivolt | 500mV | | Capacitance | 1,000 microfarads | | Other tests | Continuity | | Data types | Minimum, maximum, and average | | Display | Backlit LCD | | Wire capacity | 750 MCM or 2-500 MCM | | Safety rating | CAT III 1000V, CAT IV 600V |
|
|
|
 |
|
 |
|
|
|
 |
|
 |
|
Descripcion
Kit Eléctrico. Incluye Un Termómetro Visual Infrarrojo VT04, Un Multímetro Digital 117 y Un Amperímetro de Gancho 376 para Solucionar Problemas en Aplicaciones Eléctricas, HVAC/R y Automotrices.
|
|
|
|
|
|
|
|
|
