| Basic specifications (Accuracy guaranteed for 1 year) |  |
| DC Voltage | 600.0 mV to 600.0 V, 4 ranges, Basic accuracy: ±0.5 % rdg. ±5 dgt. | AC Voltage
40 to 500Hz | 6.000 V to 600.0 V, 3 ranges, Frequency characteristics: 40 Hz - 1 kHz
Basic accuracy: ±1.0 % rdg. ±3 dgt. (True RMS, crest factor 3) | | Resistance | 600.0 Ω to 60.00 MΩ, 6 ranges, Basic accuracy: ±0.9 % rdg. ±5 dgt. | | C (capacitance) | 1.000 μF to 10.00 mF, 5 ranges, Basic accuracy: ±1.9 % rdg. ±5 dgt. | | Frequency | AC V measurement: 99.99 Hz (5 Hz or more) to 9.999 kHz, 3 ranges
Basic accuracy: ±0.1 % rdg. ±2 dgt. | | Continuity Check | Continuity threshold [ON]: 25 Ω or less (buzzer sound), [OFF]: 245 Ω or more
Response time: 0.5 ms or more | | Diode test | Open terminal voltage: 2.5 V or less, Testing current 0.5 mA or less, Threshold of forward voltage: 0.15 V to 1.5 V | | Voltage Detection | N/A | | Other functions | Filter function, Display value hold, Relative display, Auto-power save | | Display | Main and Sub displays: 4-digits LCD, max. 6000 digits, bar graph | | Display refresh rates | 5 times/s (Capacitance measurement: 0.05 to 5 times/s, depending on measured value, Frequency: 1 to 2 time/s ) | | Power supply | LR03 alkaline batteries ×4, Continuous use: 40 hours (back light OFF) | | Dimensions and mass | 72 mm (2.83 in)W × 149 mm (5.87 in)H× 38 mm (1.50 in)D,190 g (6.7 oz) (with batteries and holster) | | Accessories | TEST LEAD DT4911 ×1, Holster ×1, Instruction Manual ×1, LR03 Alkaline Battery ×1 |
|
|
|
|
|
 |
|
 |
|
|
|
 |
|
 |
|
Descripcion
Funciones profesionales en un multímetro digital de bolsillo
Seguridad de alto nivel, cuerpo compacto y diseño de peso ligero
Cables de prueba convenientemente envolver alrededor de la parte posterior
± V DC precisión básica del 0,5%, fuera 40 Hz a 1 kHz características de frecuencia de CA V
Filtro de paso bajo (100Hz/500Hz) corta armónicos altos
Función de medida actual eliminado para mejorar la seguridad
Amplio -10 (14 ° F) a 50 ° C (122 ° F) Rango de temperatura de funcionamiento
|
|
|
|
|
|
|
|
|
