Un osciloscopio es una potente herramienta de visualización, pero su verdadero poder de medición proviene de los accesorios que se utilizan con él. La elección correcta de una punta de prueba (o sonda) es el factor más importante para garantizar la integridad de la señal y obtener mediciones precisas.
En Final Test, ofrecemos un catálogo completo de accesorios para osciloscopio compatibles con las marcas líderes como Tektronix, Rigol, Keysight y Fluke, diseñados para cada aplicación de prueba específica.
Puntas de Prueba de Voltaje: Son el accesorio más común. Incluyen puntas pasivas (como la Tektronix P2220) para mediciones generales, puntas activas para señales de alta frecuencia y sondas diferenciales y de alto voltaje para mediciones seguras en electrónica de potencia o señales flotantes.
Puntas de Prueba de Corriente: Permiten a su osciloscopio medir formas de onda de corriente AC y DC (como las series A622 de Tektronix o i400s de Fluke). Son indispensables para el análisis de fuentes de poder, motores y electrónica de potencia.
Software y Módulos: Expanda la capacidad de su equipo con módulos de aplicación para análisis de buses seriales (I2C, SPI), pruebas de EMI o análisis de potencia.
Encuentre la sonda de voltaje, punta de corriente o módulo de software adecuado para su osciloscopio. Explore nuestro catálogo de accesorios Tektronix, Rigol y Fluke.
![](\"http://www.tek.com/site/ps/60-15081/images/A000_0785-N.jpg\")
This \"long nose\" style clamp-on probe uses a Hall Effect current sensor to provide a voltage output to oscilloscopes. It has a BNC connector and may be used with a shrouded banana plug adapter*1 so it can also be used on digital multimeters, TekMeter, and scopes. The A622 can measure AC/DC currents from 50 mA to 100 A peak over a frequency range of DC to 100 kHz. It provides 10 mV or 100 mV output for each Amp measured.
\r\nProbe Compatibility Chart
\r\n\r\n
| \r\n Part # | \r\n\r\n Description | \r\n\r\n DMM100*1 | \r\n\r\n DMM200*1 | \r\n\r\n DMM910*1 | \r\n\r\n THS700*1 | \r\n\r\n TX3/TX1*1 |
|---|---|---|---|---|---|---|
| \r\n A621 | \r\n\r\n AC Current Probe, 2000 A | \r\n\r\n Yes | \r\n\r\n Yes | \r\n\r\n Yes | \r\n\r\n Yes | \r\n\r\n yes |
| \r\n A622 | \r\n\r\n AC/DC Current Probe, 100 A | \r\n\r\n Yes | \r\n\r\n Yes | \r\n\r\n Yes | \r\n\r\n Yes | \r\n\r\n yes |
\r\n
| \r\n
| \r\n\r\n A621 | \r\n\r\n A622 |
|---|---|---|
| \r\n Frequency Range | \r\n\r\n 5 Hz to 50 kHz | \r\n\r\n DC to 100 kHz |
| \r\n Max. Input Current | \r\n\r\n 2000 A peak | \r\n\r\n 100 A peak |
| \r\n Output | \r\n\r\n 1 mV / A 10 mV / A 100 mV / A | \r\n\r\n 10 mV / A 100 mV / A |
| \r\n Max. Conductor Diameter | \r\n\r\n 54 mm (2.13 in.) | \r\n\r\n 11.8 mm (0.46 in.) |
| \r\n Termination | \r\n\r\n BNC *1 | \r\n\r\n BNC *1 |
| \r\n Max. Bare Wire Voltage | \r\n\r\n 600 V (CATIII) | \r\n\r\n 600 V (CATIII) |
| \r\n Safety | \r\n\r\n UL3111-2-032 \r\nCSA1010.2.032 \r\nEN61010-2-032 \r\nIEC61010-2-032 | \r\n\r\n UL3111-2-032 \r\nCSA1010.2.032 \r\nEN61010-2-032 \r\nIEC61010-2-032 |
![\"\"](\"/v/vspfiles/assets/images/pdf-logo.jpg\"){kind=logo}
Ver Hoja de Datos en formato PDF","productFeatures":"\r\nLa A622 son puntas de corriente de alto valor especificamente diseñadas para hacer mediciones de corriente con su multimetro u osciloscopio
Esta punta estilo \"Nariz Larga\" usa un sensor de efecto Hall para proveer salida de voltaje a los osciloscopios. Tiene conector BNC y puede ser usado con un adaptador BNC a Banana para conectarla a multimetros digitales. La A622 puede medir corrientes de AC y DC desde los 50 mA hasta los 100 A pico con un rango de frecuencia de DC a 100 kHz. Provee una salida de 10mV o 100 mV por cada ampere medido.
\r\n
| \r\n
| \r\n\r\n
| \r\n\r\n A622 |
|---|---|---|
| \r\n Frequency Range | \r\n\r\n
| \r\n\r\n DC to 100 kHz |
| \r\n Max. Input Current | \r\n\r\n
| \r\n\r\n 100 A peak |
| \r\n Output | \r\n\r\n
| \r\n\r\n 10 mV / A 100 mV / A |
| \r\n Max. Conductor Diameter | \r\n\r\n
| \r\n\r\n 11.8 mm (0.46 in.) |
| \r\n Termination | \r\n\r\n
| \r\n\r\n BNC *1 |
| \r\n Max. Bare Wire Voltage | \r\n\r\n
| \r\n\r\n 600 V (CATIII) |
| \r\n Safety | \r\n\r\n
| \r\n\r\n UL3111-2-032 \r\nCSA1010.2.032 \r\nEN61010-2-032 \r\nIEC61010-2-032 |
Ver Hoja de Datos en formato PDF","productFeatures":"\r\n*1 Derated with Duty Cycle
\r\n*2 Requires a TDS TEKPROBE Oscilloscope or a TekConnect Oscilloscope with TCA-BNC
\r\nThe TCP300 and TCP400 series AC/DC Current Measurement family is a highly advanced current measurement system for today's current measurement needs. The split-core probes incorporate both transformer and Hall effect technology to provide broad bandwidth measurement capabilities from DC up to 100 MHz at current levels as low as 1 milliamp to thousands of amps (when used with CT4 current transformer). When connected to Tektronix TDS Oscilloscopes with TEKPROBE Level II or TekConnect (w/TCA-BNC) interfaces, current measurements and calculations are simple and easy.
\r\nAdditional measurement power is available with add on software such as the TDSPWR2 power measurements package. With all this measurement power, current measurements have never been easier.
\r\nThe TCPA300 amplifier, when used with TCP312, TCP305, or TCP303 probes, provide a wide range of current measurement capability and spans the gap between low level milliamp measurements to very high current levels. These three probes provide current measurement capabilities of 30A, 50A, and 150A DC continuous. For even higher current levels, the TCPA400 amplifier with the TCP404XL current probe measures 500A DC continuous and 750A DC continuous, derated with duty cycle.
\r\nHigher frequency performance is available with the TCP312 w/TCPA300 providing ¡Ý100 MHz bandwidth and a maximum current of 30A DC.
\r\nWith this new series of current measurement tools, automatic control and on-screen scaling and units is provided for users of Tektronix TDS3000, TDS500, TDS600, TDS700, TDS5000, TDS6000, and TDS7000B series oscilloscope systems. TDS series oscilloscopes provide on-screen scaling and units. Status LEDs quickly show you TCP300/400 series operating status or potential error conditions that may have caused measurement errors in the past.
\r\nThe TCP300/TCP400 Current Measurement Systems seamlessly integrate with your TDS series oscilloscope and the TDSPWR2 software package to easily make those time consuming power measurements and calculations for you.
\r\nEven non-TEKPROBE systems can use the TCPA 300/400 series to make proper current measurements by simply multiplying the measured output voltage on the oscilloscope by the TCPA 300/400 series range setting.
